ABB AF26-30-00-13 | 1SBL237001R1300 – Contactor, 3 poles, 45A, 20HP/600V (7.5HP/240 15HP/480) – Coil 100-250VADC

88,88$

The AF26-30-00-13 is a three-pole contactor – 690 V IEC or 600 UL with screw terminals, controlling motors up to 11 kW / 400 V AC (AC-3) or 15 hp / 480 V UL and switching power circuits up to 45 A (AC-1) or 45 A UL for general use.

CONTACT US

43 in stock (can be backordered)

Main Inventory43

Shipping Policy HERE.

SKU Manufacturer: AF26-30-00-13 Delivery delay if backorders: 48Hrs Categories: ,
Additional information
Weight 325 g
Dimensions 45 × 86 × 86 mm
Product Type

Contactor

Type/Class

AF

Voltage

600v

Amperage

45a

Power

20HP

Number of connection

3

Coil voltage

100-250vac/dc

Description

ABB AF26-30-00-13 | 1SBL237001R1300 – Contactor, 3 poles, 45A, 20HP/600V (7.5HP/240 15HP/480) – Coil 100-250VADC

The AF26-30-00-13 is a three-pole contactor – 690 V IEC or 600 UL with screw terminals, controlling motors up to 11 kW / 400 V AC (AC-3) or 15 hp / 480 V UL and switching power circuits up to 45 A (AC-1) or 45 A UL for general use.

Thanks to AF technology, the contactor has a wide control voltage range. (100-250 V 50/60 Hz and DC), handling wide variations in control voltage, reducing panel power consumption and guaranteeing distinct operation in unstable networks. In addition, overvoltage protection is integrated, providing a compact solution. AF contactors have a block-type design, and can be easily extended with additional auxiliary contact blocks and a wide range of additional accessories.

Applications

For controlling power circuits up to 690 V AC and 220 V DC, for controlling three-phase motors, non-inductive or slightly inductive loads. ABB- Line – a system concept designed for easy and safe installation and maintenance. Easy to integrate with other system components, compact design and a full range of accessories. Compliant with the latest international and national standards and improved environmental performance.

Specification Description – ABB AF26-30-00-13 | 1SBL237001R1300
  • Coil voltage: 100 – 250 V a.c. at 50/60 Hz, 100 – 250 V d.c.
  • Contact configuration: 3 NO (main)
  • Power: 6.5 kW at 220/230/240 V, 11 kW at 380/400/415 V, 15 kW at 440/500/690 V
  • Connection: screw terminal
  • Size: 45 mm wide x 86 mm high x 86 mm deep
  • Selection temperature: fitted with thermal overload relay: -25 to +60°C, without thermal overload relay: -40 to +70°C
  • Operating times: 40 – 95 ms (NO closing), 38 – 90 ms (NC opening) between coil energization, 11 – 95 ms (NO opening), 13 – 98 ms (NC closing) between coil de-energization.
  • Stripping length: 12 mm
    Screwdriver type: flat 5.5 diameter / Pozidriv 2
  • Maximum breaking capacity: 200 A at 690 V, 500 A at 440 V
  • Tightening torque: 22 in-lb (main circuit), 11 in-lb (control circuit)
  • Rated power Mr: 20 hp at 550 – 600 V a.c.
  • Endurance: mechanical: 10 million cycles
  • Rated voltage: 600 V (UL/CSA/NEMA), 690 V (IEC)
  • Wire size: (1 or 2) 14 – 8 AWG (main)
  • Impulse withstand voltage: 6 kV
  • Insulation voltage: 690 V (IEC 60947-4-1), 600 V (UL/CS) Number of poles: 3
  • Enclosure: IP20
  • Operating current: 45 A at 40 °C, 40 A at 60 °C, 32 A at 70 °C
  • Environmental conditions: maximum operation Permissible altitude: 3000 m, storage temperature: -60 to +80 degrees C
You have questions? Contact us for more information! Click here

Also available : ABB AF26-30-00-11 | 1SBL237001R1100 – Contactor, 3 poles, 45A, 20HP/600V (7.5HP/240 15HP/480) – Coil 24-60VADC



CA product : PC600V45A-100-250

Manufacturer : ABB

SKU : AF26-30-00-13 | 1SBL237001R1300

Manufacturer’s technical data : Click here!
