3004142 Phoenix Contact 8-mm fuse terminal block, 110–250 V AC/DC, 6.3 A, with LED indicator for glass fuse

Terminal block with fuses, fuse type: Glass / Ceramic / …, fuse type: G / 5 x 20 / 5 x 25 / 5 x 30, rated voltage: 250 V, rated current: 6.3 A, number of poles: 1, connection type: Screw connection, reference cross-section: 4mm², cross-section: 0.2mm²–4mm², mounting type: NS 35/7.5, NS 35/15, NS 32, color: black

Minimize your revenue losses and get your equipment back up and running quickly! Order now



18,34$

1479 in stock (can be backordered)

Warwick, QC225

Montréal, QC38

Ontario, ON47

USA1169

Delivery delay if backorders: 48Hrs
Product CA : PPF250V
Manufacturer : Phoenix Contact
SKU : 3004142

CAN'T FIND EXACTLY WHAT YOU'RE LOOKING FOR?

Tell us about your project, and we'll help you find the right solution.

Our store displays only a portion of the products we can supply.

Thanks to our network of certified manufacturers and distributors, we have access to thousands of additional industrial components and equipment.

Additional information
Weight 19,6 g
Dimensions 72,5 × 8,2 × 56,5 mm
Product Type Fuse Holders
Voltage 250v
Amperage 6,3a
Mounting Rail din 35mm
Length (mm) 72,5
Width (mm) 8,2
Height (mm) 56,5
Type A connection Screwed
AWG Min : 24
AWG Max : 12
Number of connection 2
Indicator 110–250 VAC/DC
Approbation CSA
Description

3004142 Phoenix Contact Fuse Terminal Block for 5×20/5×25/5×30 fuses, cross-section: 0.2–4 mm², AWG: 26–10, width: 8.2 mm, color: black

The UK series of modular fuse terminal blocks provides excellent protection for electrical systems, safeguarding them against overcurrent and short circuits. Easily clipped onto a DIN rail, the range is readily interchangeable, offering greater flexibility in installation.

Competitive pricing and dispatched within 24h

SPECIFIC FEATURES

  • Series: UK-5-HESILED 24
  • Number of poles: 1
  • Connection: screw-type
  • Cross-sectional area: 0.2 mm² – 4 mm²
  • AWG: 24 – 12
  • Color: black
  • LED

BENEFITS:

  • Large-Format Labeling
  • Flap-opening compartment for holding a fuse
  • Safety lever locked in the end position
  • Hinged disconnect lever
  • Versions with indicator light



If this product is in stock, it means we have it on hand and can ship it the same day. Minimize your lost revenue and get your equipment back up and running quickly!

Do you have any questions? Contact us! Click here



Also available:Terminal block with fuse holder – 800 V, 6.3 A (for 5 x 20 mm fuses)

Product Code: PPF250V

Manufacturer: Phoenix Contact

SKU: 3004142

Manufacturer’s technical data sheet : https://www.phoenixcontact.com/fr-ca/produits/bloc-de-jonction-fusibles-uk-5-hesila-250-3004142
