ABB AF16-30-10-13 | 1SBL177001R1310 – Contactor, 3 poles, 30A, 15HP/600V (5HP/240 10HP/480) 1NO aux. – Coil 100-250VADC

ABB AF16-30-10-13 | 1SBL177001R1310 – Contactor, 3 poles, 30A, 15HP/600V (5HP/240 10HP/480) 1NO aux. – Coil 100-250VADC

The AF16-30-10-13 is a three-pole contactor – 690 V IEC or 600 UL with 1 integral auxiliary contact and screw terminals, controlling motors up to 7.5 kW / 400 V AC (AC-3) or 10 hp / 480 V UL and switching power circuits up to 30 A (AC-1) or 30 A UL general-purpose.

Thanks to AF technology, the AF contactor has a wide control voltage range (100-250 V 50/60 Hz and DC), making it possible to handle wide variations in control voltage, reduce panel power consumption and ensure distinct operation in unstable networks. In addition, overvoltage protection is integrated, providing a compact solution. AF contactors have a block-type design, and can be easily extended with additional auxiliary contact blocks and a wide range of additional accessories.

Applications

For controlling power circuits up to 690 V AC and 220 V DC, for controlling three-phase motors, non-inductive or slightly inductive loads. ABB- Line – a system concept designed for easy and safe installation and maintenance. Easy to integrate with other system components, compact design and a full range of accessories. Compliant with the latest international and national standards and improved environmental performance.

Specification Description – ABB AF16-30-10-13 | 1SBL177001R1310

• Coil voltage: 100 – 250 V AC at 50/60 Hz, 100 – 250 V DC
• Contact configuration: 3NO (main) 1NO (auxiliary)
• Power: 4 kW at 220/230/240 V, 7.5 kW at 380/400 V 9 kW at 415/440/500/690 V
• Connection: Screw terminal
• Size: 45 mm Width X 86 mm Height X 77 m Depth
• Operating temperature: Equipped with thermal overload relay: -25 to +60 °C, without thermal overload relay: -40 to +70 deg C
• Operating time: 40 – 95 msec (NO closing), 38 – 90 msec (NC opening) between energizing coil, 11 – 95 msec (NO opening), 13 – 98 msec (NC closing) between energizing coil
• Stripping length: 10 mm
• Type of screwdriver : Flat Diameter 5,5 / Pozidriv 2
• Maximum breaking capacity: 106 A at 690 V, 250 A at 440 V
• Motor power: 15 hp at 550 – 600 V AC
• Torque: 13 lb (main), 11 in-lbs (control and auxiliary)
• Rated voltage: 600 V (UL/CSA/NEMA), 690 V (IEC)
• Endurance: Mechanical: 10 million cycles
• Cable size: (1 or 2) 16 – 10 AWG (main), (1 or 2) 18 – 14 AWG (auxiliary)
• Enclosure: IP20
• Impulse Wstand Voltage: 6 kV
• Number of poles: 3
• Environment Conditions: Maximum allowable operating altitude: 3,000 m, storage temperature: -60 to +80 deg C
• Operating current: 30 A at 40/60 deg C, 26 A at 70 deg C
• Insulation voltage: 690 V (IEC 60947-4-1 ),00 V (UL/CSA)

Also available: ABB AF16-30-10-11 | 1SBL177001R1110 – Contactor, 3pole, 30A, 15HP/600V (5HP/240 10HP/480) 1NOaux. – Coil 24-60VADC

CA product : PC600V30A-100-250

Manufacturer : ABB

SKU: ABB AF16-30-10-13 | 1SBL177001R1310

Manufacturer’s technical data : Click here!
